PLP500Apass-through with integrated electrical socket. No power outlet goes to waste.Plug and Play capability ensurers that the powerline adapter acts just like a physical network cable between power sockets without any configuration.
Applications
The PLP500A is ready for multimedia home networking, Voice and TV over IP applications:
HPAV bridge to Ethernet adapters
High Definition (HD) and Standard Definition (SD) video distribution
PC files and applications sharing
Printer and peripheral sharing
Network and interactive online gaming
Featurers
Homeplug AV and IEEE 1901 compliant, Homeplug Green PHY.
High-speed data transfer rate of up to 500Mbps, enough for HD video streaming.
System-on-a Chip(SoC) and offers lower power consumption.
Integrated Quality of Service (QoS).
Enhancements: contention-free access, our-level priority based contention access, and multi segment bursting.
Technology SPEC
Protocol | IEEE 1901 and HomePlug AV Homeplug Green PHY. 10/100 802.3az Ethernet PHY Co-exists with existing HomePlug 1.0 |
Operating systems | MAC,Windows 98SE, 2000, ME, XP 32/64 bit ,Vista 32/64bit, Windows7 32/64bit |
PLC Rate | 500Mbps |
Data Rate- TCP/UDP | 95Mbps TCP 95Mbps UDP |
Modulation Band | 2-68MHz |
Modulation Schemes | Supports256/64/16/8-QAM, QPSK,BPSK and ROBO |
Encryption | 128 AES |
Work Mode | TDMA and priority based CSMA/CA |
Multicast Support | Supports IGMP managed multicast sessions |
Typical Coverage | Up to 5000 square foot home The actual Coverage will vary with the power grid and the number of PLC terminal device. |
LED’s | Power Ethernet: Ethernet Link and Activity Data: PLC Link and Activity |
Power supply | AC 85 to 256 V, 50/60Hz |
ACr Output | 220VAC 16A Maximum,110VAC 20A Maximum |
Filter characteristics | -40dB to -70dB |
Consumption | <2.5W |
Plug Type | EU, UK AU and FR |
Ethernet Interface | 1 x RJ45 for 10/100 Ethernet (Auto MDI/MDI-X) |
Operating Temperature | 0ºto 70ºC |
Operating Humidity | 10% to 90% Non-condensing |
Storage Temperature | -40ºto 85ºC |
Storage Humidity | 5% to 90% Non-Condensing |
