Main Features ●Batttery Low Protection
●Over load protection
●Short circuit protection
●Over-temp protection
●input reverse polarity protection
●Applications:light,TV ，Fan set

Overview

MODEL		SK-120W	SK-150W	SK-300W	SK-600W	SK-1000W	SK-1500W
DC Input	rated power(VA)	120	150	300	600	1000	1500
	rated voltage(Vdc)	12	12	12	12	24	24
AC output	actual power(W)	70%
	voltage(VAC)	220+/-10%
	Frequency(Hz)	50+/-1Hz
	overload capacity	150% 10sec
	peak efficiency	>=80%
	wave form	modified sine wave
	circuit	IC
Auto protection		battery low voltage protection
		output overload protection
		short circuit protection
		input reverse polarity protection
Environment	Noise(dB)	<=40 (1 mter)
	Temperature	-20~45 degree
	Humidity	0~95% ( no condensation)
	Sea Level(m)	<=1500
carton dimension	L x W x H(mm)	415x330x220		345x260x470		345x260x470
unit per carton	pcs	8	8	2	2	2	2
weight(kg)	per carton	15	17	10	15	19	23
qty(pc)	20 feet container	7300	7300	1320	1320	1320	1200
