SKN-P 1000watt series

SKU: FS00019505

Reproduction is welcome and allowed for free circulation only.

Main Features ●Pure sine wave output (THD<3%)
●Power ON-OFF switch
●Input voltage range:-15% ~ +25%
●Output voltage regulation:±10%
●Thermo control cooling fan
●Two-color indicators display power and fault status
●Protections:short circuit, overload, over temperature, low
●battery voltage, over battery voltage, lack-voltage alarm.
●Topology: Microprocessor
●Approvals: RoHS / CE / EMC / LVD
●1 year warranty

Overview

Model No.		SKN-P1000 -112A1	SKN-P1000 -124A1	SKN-P1000 -148A1	SKN-P1000 -112B2	SKN-P1000 -124B2	SKN-P1000 -148B2
Output	AC voltage	110V±10%			220V±10%
	Rated power	1000W			1000W
	Peak power	2000W			2000W
	Waveform (THD)	Pure sine wave (<3%)			Pure sine wave (<3%)
	Frequency	60Hz ±0.3%			50Hz ±0.3%
Input	NO load current draw	<1A	<1A	<1A	<1A	<1A	<1A
	DC voltage	12V	24V	48V	12V	24V	48V
	Voltage range	10.8~15VDC	21~30VDC	41~56VDC	10.8~15VDC	21~30VDC	41~56VDC
	Efficiency	> 90%			> 90%
	DC connector	Cables With Clips or Car Adaptor			Cables With Clips or Car Adaptor
Protection	Low voltage alarm	10.2～10.8V	20.4V	40.8V	10.2～10.8V	20.4V	40.8V
	Low voltage shut down	DC 9.5V	DC 19.5V	DC 38.5V	DC 9.5V	DC 19.5V	DC 38.5V
	Over load	Shut Off Output			Shut Off Output
	Over voltage shut down	DC 15.5V	DC 30.5V	DC 61.2V	DC 15.5V	DC 30.5V	DC 61.2V
	Over thermal	Shut Off Output Automatically			Shut Off Output Automatically
	Fuses	Short Circuit			Short Circuit
Environment	Working temperature	-10°c ~ +50°c			-10°c ~ +50°c
	Working humidity	10%~90%RH			10%~90%RH
	Storage temperature	-20°c ~ +50°c			-20°c ~ +50°c
Package	Machine Size(mm)	32313972			32313972
	Packing Size(mm)	368180120			368180120
	Net Weight	2.7kg/unit			2.7kg/unit
	Gross Weight	3.5kg/unit			3.5kg/unit
	Packing Mode	Carton			Carton
Other	Start	Soft Start			Soft Start
	Cooling Ways	Cooling Fan			Cooling Fan
