| ●True On-line double conversion design providing all power protection | ||
| ●Sine wave pluse width modulation | ||
| ●IGBT Iinverter design | ||
| ●Wide input voltage range | ||
| ●Pure sine wave output with less than 3% THD | ||
| ●Expandable backup time | ||
| ●Generator compatible | ||
| ●Load/battery power LCD display | ||
| ●Overload,on-line,battery status LED+LCD | ||
| ●Advanced Battery Management | ||
| ●Automatically charging in ups OFF mode | ||
| ●Zero transfer time on AC mode to/from battery,AC mode to/from bypass | ||
| ●Smart RS232 communication port | ||
| ●Optional SNMP cards | ||
| Overview |
| Series | SKS Series | ||||||||||
| Model | 1KVA | 2KVA | 3KVA | 4KVA | 6KVA | 8KVA | 10KVA | 12KVA | 15KVA | 20KVA | |
| Capacity(w) | 0.8KW | 1.6KW | 2.4KW | 3.2KW | 4.8KW | 6.4KW | 8KW | 9.6KW | 12KW | 16KW | |
| Input | Voltage Range | 180~260VAC or 90~130VAC | |||||||||
| Frequency | 50/60HZ±5% | ||||||||||
| Phase | Single phase+GND | ||||||||||
| Max input current(110V) | 12A | 20A | 48A | 28A | 68A | 90A | 110A | 136A | 168A | 220A | |
| Max input current(220V) | 6A | 10A | 14A | 24A | 34A | 45A | 56A | 68A | 84A | 112A | |
| Output | Voltage Range | 220VAC±1%or110VAC±1% | |||||||||
| Frequency | 50/60HZ±0.5% | ||||||||||
| Phase | Single phase+GND | ||||||||||
| THD | ＜3%(linear load) | ||||||||||
| Power Factor | 0.8 | ||||||||||
| Short Circuit Protection | Current limit,turn off automatically,Switch protect | ||||||||||
| Overload Capacity | Overload(110%-150%),20s later go to bypass, automatically resume when load become normal | ||||||||||
| Battery | Type | Sealed lead acid,maintenance free | |||||||||
| DC | 48VDC(192V Optional) | 192VDC | |||||||||
| Charge current | 4.2A | 4.2A | 4.2A | 4.2A | 4.2A | 4.2A | 4.2A | 4.2A | 4.2A | 4.2A | |
| Charge Time | 90% capacity after 8 hours | ||||||||||
| Panel indication | LCD | Working mode,I/P and O/P voltage,I/P and O/P frequency, Battery voltage,load percentage,UPS inner temperature | |||||||||
| LED | low battery,online,inverter,bypass,abnormal | ||||||||||
| Efficiency | Whole unit | 0.8 | |||||||||
| Communication |
| 1.Power status 2.UPS shutdown 3.monitor UPS status 4.UPS self test 5.auto-save files | |||||||||
| Protection | Surge Protection | IEEE527B | |||||||||
| Noise | FCC.A | ||||||||||
| Audible Noise |
| ＜55DB (at 1 meter) | |||||||||
| Environment | Temperature | 0~40℃ | |||||||||
| Humidity | 0%~95% | ||||||||||
| General | Net weight(without battery) | 46kg | 63kg | 75kg | 65kg | 69kg | 105kg | 115kg | 120kg | 210kg | 250kg |
| Packing(W×D×H)mm | 320×620×730 | 350×725×810 | 470×765×916 | 726×485×1176 | |||||||
