16CH H. 264 Network Economic Standalone DVR fj-9216AV
16CH H. 264 network Economic standalone DVR (fj-9216V)
Economic DVR;
1. Support 16 CH CIF realtime recording resolution
2. Supply our own free DDNS: No longer to register domain name
3. Support Multiple channel playback at the same time(Support 8 CH playback simultaneously)
4. Support Network function: One IE browser centralized monitoring and CMS Software for multiple DVR (up to 255 DVR simultaneously)
5. Support Mobile phone Remote Viewing: Symbian S60 V3/V5; Windows Mobile; Android; iPhone; Blackberry;
| Video Compression Format | H. 264 |
| Video System | NTSC / PAL |
| GUI OSD | YES |
| Video Input(BNC) | 16CH BNC input(composite video signal 1Vp-p 75Ω BNC) |
| Video Output(BNC) | 1CH BNC output |
| Audio Input/Output | 2CH audio input, 1CH audio output(RCA) |
| Maximum Recording Rate (4CH D1 real time) | CIF: NTSC: 352 x 240 pixels with 480IPS PAL: 352 x 288 pixels with 400IPS QCIF: NTSC: 176 x 120 pixels with 480IPS PAL: 176 x 144 pixels with 400IPS |
| Image Quality Setting | Supper Best, Well, Good, Medium, Normal and Bad |
| Hard Disk Storage | Support 1SATA HDD, Max Capacity: 2TB |
| Alarm Input/Output (optional) | 4CH input, 1CH output |
| Multiplex Operation | Live display/record/playback/backup/network transmit |
| Recording Mode | Manual/Timer/Motion/Alarm |
| Playback Mode | Multiple slow and rapid play speeds, manual and single-frame play modes, and support of drag the sliding bar to set. |
| Backup Device | USB flash disk/USB HDD/Network/USB DVD -RW |
| Pre-alarm Recording | Recording for 10 seconds before alarming |
| Network Protocol | TCP/IP, PPPOE, DDNS, FTP, UPNP, ARSP and NTP |
| Ethernet remote view | Support remote surveillance up to 10 users simultaneously |
| CMS software | YES |
| Mobile phone View | YES |
| VGA Interface | YES |
| Log record function | YES |
| Image Tour | YES |
| IR Remote control | YES |
| Video Loss Detection | YES |
| Video Adjustable | Hue/Saturation /Contrast /Brightness adjust |
| PTZ Control | YES, built-in RS-485 port |
| USB Mouse | YES |
| Power Source | DC 12V |
| Key Lock(Password Protection) | YES |
| Power-down recovery function | YES |
| Size(mm) | 260(W) x 45(H) x234(D) |
