Picture of 2.4G Yagi Antenna

2.4G Yagi Antenna

SKU: FS00034377
2.4G Yagi Antenna
Reproduction is welcome and allowed for free circulation only.


Frequency range 2400MHZ~2483MHZ
Gain 16dBi
F/B ratio ≥14~20dB
VSWR ≤1.5
Input impedance 50Ω
Polarization Vertical or Horizontal
Max Power 20W
Connector N-J
Length 35~90cm
weight 0.4KG~1.0KG
The lightning protecting Direct-Current grounding
The wave is a width E side 40º~30º/H side 48º~30º
The unit counting 16
Resist the of wind 60M/S
Support the pole ø38~ø52MM

Product Profile
The antenna features high gain, big radiation, strong capability of anti-interference, applicable to 2400MHZ frequency section, which is specially designed for long-distance directional telecommunication, featuring simple structure, firmness, and convenient installation.
