Picture of Grid Hybrid  Power Inverter SPG500-3000W

Grid Hybrid Power Inverter SPG500-3000W

SKU: FS00018921
Reproduction is welcome and allowed for free circulation only.


Key Features
�� Low frequency pure sine wave Grid Hybrid off Grid Power Inverter

�� 3 in 1 Off Grid design, Inverter +Grid Charger+MPPT solar charge controller

�� Selectable Grid power First or Solar Power First (battery power First)

�� Transfer Time 10ms. Computer will not shut off when Mains off suddenly.

�� Digital control three stage charger, improve battery life

�� With Battery Selector for charge of different battery

�� Power saver Function (Stand by)

�� High Power Factor0.9-1,

�� Low idle current to reduce energy consumption

�� Low DC input, 1-3KW/12V (24/48) VDC, 4-6KW/24V (48) VDC

�� Big charge current, 35A-75Amp for different mode

�� Back-Feed Protection

�� Full protection, short circuit, Overload, over Temp., Battery low/high Protection

�� Fault recovery

�� LED display and alarm

�� Remove control solution

�� Rs232 communication function optional for LED Type

�� SNMP Net Agent function optional for LED type

�� Remove control cable optional

�� LCD Display is optional

Technical Specifications

Mode

SPG500

SPG1000

SPG1500

SPG2000

SPG3000

Continuous power(W)

500W

1000W

1500W

2000W

3000W

Surge capability (W)

1500W

3000W

4500W

6000W

6000W

System DC input (VDC)

12V or 24VDC

24VDCV

24VDC

24VDC

24VDC

AC Output

110 / 120V/ 220V/230V ��5% , 50HZ or 60HZ. Terminal

AC Output waveform

Pure Sine Wave

DC output

12VDC or 24VDC Terminal

Efficiency

>85%

AC/DC Charger

Max 15A

Max 25A

Max 25A

Max 40AMP

Max 50

Solar Charge Controller

MPPT,20AMP

MPPT,30AMP

MPPT,40AMP

MPPT,50AMP

MPPT 100AMP

Adviced PV

36 or 72 Cell

72 Cell

72 Cell

72 Cell

72 Cell

External battery back

12 or 24VDC

24VDC

24VDC

24VDC

24VDC

Breakers

with Breakers for AC Input , AC output, PV input , DC output

Battery low protection

yes

Over discharge protection

yes

Resume voltage

Yes. When fault remove

Over voltage protection

yes

Overload protection

Yes.

With cooling fan

yes

Display

LED for Inverter, charger, Battery Capacity state, DC load state and fault. LCD display is optional

Running Temperature

-35 degree to 55 degree

High temperature protection

YES

Short circuit protection

YES

Reverse polarity protection

YES. Only for DC load side.

Stand by

Yes. continuo output while > 25W

Communication

RS232 Power Manager, Net Agent SNMP , Optional for LED mode

Package Size(mm)

608*558*293

608*558*293

608*558*293

608*558*293

608*558*293

Gross Weight KG

21

24

24

26

32

product Size (mm)

460*440*200

460*440*200

460*440*200

460*440*200

460*440*200

product weight( kg)

15KG

16KG

16KG

19.5KG

24KG
