Catelogue: Solar DC Home Systems
Hits:
•Zeropollution
•Environmentalfriendly
•All-in-onesystem
•Easytoinstallandremove
The off-grid DC solar power system (SDC series) consists of solar panels, controller, battery. This system is designed to supply independent DC power to civil and commercial application with both DC 5V/12V output. It can be used to supply power to house hold appliances and equipments, such as DC lamps, DC fans, radio, etc. in remote areas or regions where there is no electricity supply. It can be also used for camping, outdoor working and emergency power supply, etc.
Specification
| Model number | SDC-B-200 |
| Solar panel | 40W (20Wx2pcs) monocrystalline |
| Battery | 12V18Ah AGM DC battery |
| The maximum continuous output power | 200Wh |
| Recommended output power per day | 120Wh |
| Light source | 3pcs DC 12V2W LED lamp |
| Luminous flux | 60±5 lm/w |
| The maximum continuous working hour | 33 hours (3pcs lamp); 100 hours (1pcs lamp) |
| Recommended working hour per day | 20 hours (3pcs lamp); 60 hours (1pcs lamp) |
| Charging time | 8 hours |
| Electricity charging function | yes |
| Output voltage | DC 5V/12V |
| Ambient temperature | -10℃～45℃ |
| Relative humidity | 0～85%RH |
| Operating altitude | 0～2500m |
| Size of solar panel(mm) | — |
| Weight of solar panel | — |
| Size of host case(mm) | 470×430×190 |
| Total weight | 10.5kgs |
