Picture of 5.4~5.8GHz Die Cast Grid Antenna 30dBi

5.4~5.8GHz Die Cast Grid Antenna 30dBi

SKU: FS00034631
5.4~5.8GHz Die Cast Grid Antenna 30dBi
Reproduction is welcome and allowed for free circulation only.


5.4-5.8GHz 30dBi Die Cast Grid Antenna
Model GA-5458D30A
Frequency Range 5470-5850 MHz
Bandwidth 380 MHz
Gain 30 dBi
Horizontal Beamwidth 4 º
Vertical Beamwidth 6 º
F/B Ratio ≥30 dB
V.S.W.R ≤1.5Type; Max 2.0
Nominal Impedance 50 Ω
Polarization Vertical or Horizontal
Max Power 100 W
Connector N female
Dimension 0.6×0.9 m
Weight 3.5 kg
Rated Wind Velocity 60 m/s
