Combo Antenna

SKU: FS00034556
Combo Antenna
Reproduction is welcome and allowed for free circulation only.


GPS,GSM,WIFI funtions 3 in 1.

(1) Dieletric Antenna
Center Frequency 1575.42MHz±3 MHz
V.S.W.R 1.5:1
Band Width ±5 MHz
Impendence 50 ohm
Peak Gain >3dBic Based on 7×7cm ground plane
Gain Coverage >-4dBic at –90°<0<+90°(over 75% Volume)
Polarization RHCP


(2) GSM Antenna
Center Frequency 824MHz~894MHz;880MHz~960MHz;
1710MHz~1990MHz
V.S.W.R 2.0:1
Impendence 50 ohm
Typical Gain 2dBi+/-1dB@850MHZ;
2dBi+/-1dB@900MHZ;
1dBi+/-1dB@1800MHZ; 1dBi+/-1dB@1900MHZ

(3) Wifi Antenna
Frequency Range 2400-2500 MHz
VSWR ≤1.5
Gain 2.15dBi
Impedance 50 ohm
Polarization Type Vertical

(4) LNA/Filter
LNA Gain(Without cable) 28dB Typical
Noise Figure 1.5dB
Filter Out Band Attenuation (f0=1575.42 MHZ)
7dB Min f0+/-20MHZ ;
20dB Min f0+/-50MHZ;
30dB Min f0+/-100MHZ
V.S.W.R < 2.0
DC Voltage 2.7V/3.0V/3.3V/5.0V/3.0V to 5.0V/other
DC Current 11mA Max


(5) Mechanical
Weight <240gram
Size 70mmx70mmx14mm
Cable
GPS-----RG174 2meter, 5meter long or other
GSM-----RG174 2meter, 5meter long or other
Wifi-----RG174 2meter, 5meter long or other

Connector
GPS-----SMA/SMB/SMC/BNC/FME/TNC/MCX /MMCX or other
GSM-----SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX or other
Wifi-----SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX or other

Mounting Screw Mounting
Housing Black


(6) Environmental
Working Temp. -40'C~+85'C
Storage Temp. -45'C~+100'C
Vibration Sine sweep 1g(0-p)10~50~10Hz each axis
Humidity Humidity95%~100%RH
Weatherproof 100%Waterproof
