Combo Antenna

SKU: FS00034512
Combo Antenna
Reproduction is welcome and allowed for free circulation only.


(1) Dieletric Antenna

Center Frequency 1575.42MHz±3 MHz

V.S.W.R 1.5:1

Band Width ±5 MHz

Impendence 50 ohm

Peak Gain >3dBic Based on 7×7cm ground plane

Gain Coverage >-4dBic at –90°<0<+90°(over 75% Volume)

Polarization RHCP

(2)GSM Antenna

Center Frequency 850/1900MHz or 900/1800MHz

V.S.W.R <2.0:1

Impendence 50 ohm

Typical Gain 2dBi+/-1dB@850MHZ; 2dBi+/-1dB@900MHZ;

1dBi+/-1dB@1800MHZ; 1dBi+/-1dB@1900MHZ

(3) LNA/Filter

LNA Gain(Without cable) 28dB Typical

Noise Figure 1.5dB

Filter Out Band Attenuation (f0=1575.42 MHZ)

7dB Min f0+/-20MHZ ;

20dB Min f0+/-50MHZ;

30dB Min f0+/-100MHZ

V.S.W.R <2.0

DC Voltage 2.7V/3.0V/3.3V/5.0V/3.0V to 5.0V/other

DC Current 11mA Max

(4) Mechanical

Weight <150gram

Size 46 mm(D)×14.5mm(H)

Cable GPS-----RG174 2meter, 5meter long or other

GSM-----RG174 2meter, 5meter long or other

Connector GPS-----SMA/SMB/SMC/BNC/FME/TNC/MCX /MMCX or other

GSM----SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX or other

Mounting Screw Mounting(hole or roof mounting)

Housing Black

(5) Environmental

Working Temp. -40'C~+85'C

Storage Temp. -45'C~+100'C

Vibration Sine sweep 1g(0-p)10~50~10Hz each axis

Humidity Humidity95%~100%RH

Weatherproof 100%Waterproof
