Picture of Low Frequency Online UPS TA2K-20K

Low Frequency Online UPS TA2K-20K

SKU: FS00018899
Reproduction is welcome and allowed for free circulation only.


key features:

��Single phase in, single phase out

��Microprocessor control


��True on-line double conversion design


��Sine wave pulse width modulation.


��Isolated output


��IGBT inverter design


��Wide Input voltage windows


��Pure sine wave output with less than
3%THD

��Expandable backup time


��Generator compatible


��Cold start


��Load/Battery power meter display


��Overload, on-line, battery status LED/LCD


��Advanced Battery Management


��Automatic charging in UPS off mode


��Zero transfer time


��Smart RS-232 communication port


��Optional SNMP card

Technical Specifications

MODEL

TA2K

TA3K

TA4K

TA6K

TA8K

TA10K

TA12K

TA15K

TA20K

Power capacity

2KVA

3KVA

4KVA

6KVA

8KVA

10KVA

12KVA

15KVA

20KVA

1.6KW

2.4KW

3.2KW

4.8KW

6.4kW

8KW

9.6KW

12KW

16KW

Input

Voltage Range

220V or 110V+-20%

Frequency

50/60Hz��5%

Phase

Single phase + GND

Output

Voltage Range

220VAC ��1% or 110VAC ��1%

Frequency

50/60Hz �� 0.3%

Phase

Single phase + GND

THD

< 3% (linear load), < 5%( nonlinear load)

Power Factor

0.8

Short Circuit Protection

Current limit, turn off automatically, Switch protect

Overload Capacity

Overload 125% for 10 Mins, 125%-150% for 30s .automatically resume when load become

normal

Battery

Type

Sealed lead acid, maintenance free

DC Voltage

48VDC

96VDC

192VDC

Charge current

6A

6A

6A

6A

6A

6A

6A

6A

6A

Panel indication

LCD

Input,oupt,battery voltage,frequency,load rate,UPS state, temperature

LED

Main input , bypass,Inverter, Battery,Over load,Fault

Efficiency

Whole unit

85%

Communication

1.Power status 2.UPS shutdown 3.monitor UPS status 4.UPS self test 5.auto-save files

Protection

Surge Protection

IEEE527B

Noise

FCC.A

Audible Noise

<55db (at 1 meter)

Environment

Temperature

0- -40 ��

Humidity

0%-95%
