Picture of EW2110 Series 1200VA-1500VA LCD UPS

EW2110 Series 1200VA-1500VA LCD UPS

SKU: FS00018868
Reproduction is welcome and allowed for free circulation only.

Application:

- Line interactive UPSis the perfect protection partners for computer,
- Workstations and POS system.
- Widely used in municipal, bank, postal coupons, communication transportation,radio and television, and power
- Public hospital, industrial control, defense, etc,
- Computer room, data center, and the server for electric power
- Environmental requirements of network equipments, strict communication and information.

Manual Main Features:

Fully digitized microprocessor controlled .
LCD series CPU control guarantees high reliability
Lightning and surge protection.
Cold start function (DC power on).
Equipped with AVR to stabilize output voltage wide input voltage range
Generator Compatible
Auto charging even though the UPS is off
Smart RS232 or USB communication interfaces
Sealed lead-acid, maintenance free battery
Battery low voltage, overload & short circuit protection.
Advanced automatic constant charging circuit, prolongs battery life
Automatic buck and boost AVR function, wide input voltage 155-280VAC
Lead-Acid, maintenance free battery inside, provides strong power to users.

Specifications:

MODEL EW2110 1000 EW2110 1200 EW2110 1500
CAPACITY 1000 VA /600W 1200 VA /720W 1500VA /900W
INPUT
Phase single
Voltage 110/115/120VACor220/230/240VAC
Voltage Range 81-145VAC/145-290VAC
Frequency Range 50/60 Hz ±1%(auto sensing)
OUTPUT
Phase single
Voltage (Batt. Mode) 115VAC or 230 VAC
Frequency Range (Batt. Mode) 60 Hz or 50 Hz ±1 Hz
Transfer Time Typical 2-6 ms, 10ms max.
Overload Capability 110% for 5 min, 120% immediate shutdown
Waveform (Batt. Mode) Modified SineWave
BATTERY
Battery Type & Number 12 V/7 AH x 2 12 V/7 AH x2 12 V/9 AH x 2
Typical Recharge Time 8 hours recover to 90% capacity
Backup Time(at a1 PC load with 15 monitor) 20-30 minutes 20-30minutes 20-30minutes
INDICATORS
LCD Indicator with Blue Back Light The LCD will self turn on when the UPS is functioning including in, off, charging mode and fault mode
PROTECTION
Full Protection Overload, discharge, and overcharge protection
TRANSFER TIME
Typical Typical 2-6 ms, 10ms max.
ALARM
Battery Mode Sounding every 10 seconds
Low Battery Sounding every second
Overload Sounding every 0.5 second
Battery Replacement Alarm Sounding every 2 seconds
Fault Continuously sounding
PHYSICAL
Dimension, D X W X H (mm) 368.3X140.2X180.4
Net Weight (kgs) 9.5 9.5 10
OPERATING ENVIRONMENT
Humidity 0-90 % RH @ 0- 40°C (non-condensing)
Noise Level AC Mode: Less than 40dB
Backup Mode: Less than 45dB
MANAGEMENT
Optional USB/RS-232 Port Supports Windows® 98/2000/2003/XP/Vista/2008, Windows® 7, Linux, and MAC
