Picture of HBFL series wind power generator

HBFL series wind power generator

SKU: FS00019590
Reproduction is welcome and allowed for free circulation only.

Application(HBFL series wind power generator)

Making use of wind power to generate electric power and consequently charge the storage battery, then supply thestorage electric energy to lighting, household appliances, communication equipments and motor tools in the modeof DC or AC.

Technical characteristics(HBFL series wind power generator)
1)Drive permanent magnet generator directly; the generator adopts ferromagnetic material, with 2 times ofoverload capability.
2)Starting with breeze, generating with class 2 wind, good running with low wind velocity.
3)Excellent aerofoil design, in the wind tunnel test, it shows high efficiency and low noise. The blades are madeaccording to the structure and crafts of air propeller. Firm and durable, service life as long as 15-20 years.
4)The wind wheel and motor adopt universal connection, run stably without vibration.
5)Closed power transmission slip ring, the cable will not enwind.
6)Simple and strengthened design, enables it free from special maintenance.
7)When meeting strong wind, there will be crosswind and electromagnetic speed-limiting protection.
8)Direct current charging under constant voltage.
9)Lever type independent tower, convenient installation, rising and falling.
10)Strict corrosion proof measures, anti atmosphere, fume or sand.
Specification(HBFL series wind power generator)
ModelHBFL
-200
HBFL
-300
HBFL
-500
HBFL
-1000
HBFL
-2000
HBFL
-3500
HBFL
-5000
HBFL
-7500
HBFL
-10K
HBFL
-15K
HBFL
-20K
Diameter of wind wheel (m)2.22.52.83.2456781012
Blade materialGlass fibre reinforced plastic*3
Rated wind speed (m/s)888810101010101010
Starting wind speed (m/s)3
Wind speed during working (m/s)3-254-30
Safe wind speed (m/s)4050
Rated power (W)20030050010002000350050007500100001500020000
Max power (W)30050080015003000450065009000150002100030000
Rated rotating speed (r/min)45042040036028022019016012010095
Generator formPermanent magnet generator, three-phase, AC
Speed-limiting modeLateral misalignment and electromagnetic braking
Working voltage (V)DC24/36V AC220VDC48/240V AC220VDC240V/500V AC220/380VDC500V AC380V
Tower height (m)5.5667881010/1210/1510/1510/15
Weight (not include tower) kg67809012022030060066580013001600
Weight of A/AA steel pipe zipper (kg)406585100160150800800(10m)1000(12m)1500(15m)1650(15m)
Weight of independent mast (kg)23025028035038045013001300(10m)1800(10m)2800(15m)2800(15m)
A/AA volume (CBM)0.50.50.50.610.74.44.55.26.56.5
AAA volume (CBM)0.50.50.70.81.31.36.26.37.48.59.6
AA--special corrosion proof, steel pipe zipper type mast; AAA--special corrosion proof, independent mast of manganese steel material, more convenient installation, elegant, small floor space required
